AC Motor Cable Powered 50 Tons Heavy Duty Material Rail Transfer Trolley
Henan Remarkable's 50 Tons Heavy Duty Material Rail Transfer Trolley, Also Known As Cross Flat Cart, Transfer Trolley,Electric Flat Cart, Have Advantages As Simple Structure, Easy Operation And Maintenance,Large Load Capacity And So On, With Which These Transfer Carts Are Widely Used In Machine Manufacturing And Metallurgical Factory Matching Up With Lift Cranes To Transport Heavy Objects Warehouse Across.
How Can Transfer Carts Be Customized?
Please Tell Us:
What Load Or Product Will Be Transferred Onto The Cart?
What Is The Weight Of The Heaviest Lift Or Load?
What Are The Dimensions? (Length; Width ; Height)
What Is The Trip Time And Frequency? (# Of Trips Per , Shifts Per Day:)
What Is The Travel Area You Need To Cover? (Rail/Cement Floor, Indoor/Outdoor, Straight Line Travel, Etc)
What Is The Distance To Travel?
Other Relevant Information Or Using Condition.
| Technical parameters for Cable reel powered electric transfer carts KPJ series |
| Model | KPJ-6t | KPJ-10t | KPJ-16t | KPJ-25t | KPJ-40t | KPJ-63t | KPJ-100t | KPJ-160t | KPJ-200t |
| Rated load (t) | 6 | 10 | 16 | 25 | 40 | 63 | 100 | 160 | 200 |
| Countertop size | Length | 3600 | 3600 | 4000 | 4500 | 5000 | 5600 | 6300 | 8000 | 8200 |
| (mm) | Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2800 | 2800 | 3000 |
| | Height | 550 | 550 | 600 | 650 | 700 | 850 | 900 | 1150 | 1250 |
| Speed(m/min) | 30 | 30 | 30 | 30 | 25 | 25 | 20 | 20 | 18 |
| Wheel base A(mm) | 2000 | 2200 | 2200 | 2500 | 2800 | 3200 | 3600 | 5000 | 5000 |
| Track medial distance C(mm) | 1435 | 1435 | 1435 | 1435 | 1635 | 1735 | 1850 | 2000 | 2000 |
| Wheel diameter(mm) | 300 | 300 | 400 | 400 | 500 | 600 | 700 | 700 | 700 |
| Bottom clearance(mm) | 50 | 50 | 50 | 60 | 60 | 60 | 60 | 70 | 70 |
| Motor model / power | YZ132M1-6 | YZ132M2-6 | YZ160M1-6 | YZ160M2-6 | YZ160L-6 | YZ160M2-6 | YZ160L-6 |
| (Kw) | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 2×7.5 | 2×11 |
| Power mode | Cable drum | AC380V | AC380V | AC380V |
| 3×2.5+1×1.5 | 3×4+1×2.5 | 3×6+1×4 |
| Recommended track model | 24kg/m | 24kg/m | 38kg/m | 43kg/m | QU80 | QU100 |
| Number of wheels | 4 | 8 |
| Maximum wheel Pressure (t) | 1.91 | 3.21 | 4.87 | 7.5 | 11.5 | 16.9 | 27.6 | 22.8 | 28.5 |
| Reference weight (t) | 3.4 | 3.72 | 4.2 | 6 | 8.5 | 11.4 | 15.2 | 25.5 | 31.5 |
50 Tons Cable Powered Transfer Car Apply For Painting Workshop, Also Called Transfer Trolley, Transfer Cart And Climbing Transfer Cart, Is A Kind Of Electric Material Handling Equipment. This Kind Of Rail Handling Vehicle Is Powered By Cable Reel (Also Called Cable Drum) To Drive Wheels And Make The Vehicle Start, Stop, Go Forward And Backward, Speed Up And Slow Down And So On. This Rail Handling Vehicle Can Be Used Both On The "S" And Arc-Shaped Railways.
Characters Of 50 Tons Heavy Load Electric Rail Handling Vehicle
· Anti-Explosion
· Anti-High Temperature
· Apply To Various Occasions
· Stable Start, Big Starting Power, Small Impact To The Gear Reducer, Low Voltage, Long Lifetime And So On.
· It Has No Strict Requirement For The Construction Of The Railway.
· No Limit Of Running Hours
· Safe And Convenient Operation For There Is No Wire Outside The Vehicle
· Adjustable Speed
